SPECIFICATIONS
Dimensions and Weight
- Height: 125 mm
- Width: 125 mm
- Depth: 54.2 mm (bracket included) / 24.5 mm (bracket not included)
- Weight: About 155 g (excluding the power adapter)
5G/4G
- 4G Transmission Rate:
+ Max.DL: 195 Mbps
+ Max.UL: 105 Mbps
Wi-Fi
- Transmission Standard: Wi-Fi 4
- Wireless Transmission Rate: 2.4 GHz: 300 Mbps（theoretical value）
- Wireless Frequency Band: 2.4 GHz
Antenna
- 5G/4G Antenna Type: Built-in 4G main and diversity antennas, external antennas can be removable
- WLAN Antenna Type: Built-in 2.4G Wi-Fi antenna, non-removable
Memory
- RAM: 128 MB
- ROM: 128 MB
Interface
- External Antenna Ports (SMA): 1
- 100 Mbps LAN/WAN Port (RJ45): 1
- Power Port: 1
- Nano-SIM Card Slot: 1
Button
- WPS Button: 1
- Reset Button: 1
LED Indicator
- Internet Status Indicator: 1
- Wi-Fi Indicator: 1
- Signal Strength Indicators: 3
Power Supply
- Power: < 12 W
- AC / DC Power Supply: AC: 100V～240V DC: 12V/1A
Software Functions
- HUAWEI AI Life App
Security
- Anti-brute Force Cracking: Supported
- Firewall: Supported
- DoS Attack Protection: Supported
- Wi-Fi Encryption Authentication: Supported WPA-PSK/WPA2-PSK/WPA3-SAE
Environment
- Temperature:
+ Operating Temperature: 0°C ~ 40°C
+ Storage Temperature: -20°C ~ +70°C
PACKING LIST
- CPE: 1 (Standard)
- Quick Start Guide: 1 (Standard)
- Power Adapter: 1 (Standard)
- Ethernet Cable: 1 (Optional)
- Warranty Card: 1 (Optional)
- External Antenna: 1 (Optional)
